The Dragon – proiect STL 3D

3D MODEL DESCRIPTION

A dragon’s breath is deadly, sure. But look on the bright side! Literally, I mean. It makes your room much brighter.
This STL file is recommended for FDM Printers!
3D Printing Time: 21 Hours 09 Minutes
Approximately Height: 17 cm

3D PRINT FILE SETTINGS (FOR 0.4 MM NOZZLE)

Line Width/ Nozzle: 0.4 mm
First Layer Line Width: 0.48 mm / 120%
Average Speed: 20mm/s (First Layer) / 50mm/s (All the other layers) | 20 mm/s (First Layer) / 500 mm/s (All the other layers on Bambu Lab)
Recommended Initial Layer Height: 0.20 mm
Recommended Layer Height: 0.20 mm
Recommended Perimeters/ Walls: 3.
Recommended Infill (%): 10% (Gyroid)
Needs Support: Yes.
Build Plate Adhesion: Skirt. The parameters above are recommendations made by our staff; if you prefer, you can adapt them according to your preferences. Happy Printing! 3D MODEL ASSEMBLY INSTRUCTIONS In order to assembly this print you will need the materials below: LED Lights (FLAT TOP) On-Off Switch Solder Soldering Iron Electric Wire Electrical Plug (2.1mm DC Jack 12V) Power Supply (12V 1A) Electrical Tape 1- Thread the LED Flat Top through the front part of the LED support, according to the picture. 2- Cut a 6 cm piece of wire and attach one of its ends to the on/off switch. 3- Place the on/off switch on its designed place on the printed model, then connect the red LED wire to the remaining side of the on/off switch. 4- Place the 12V plug on its designed place on the printed model and connect the red wire from the on/off switch onto the smaller side of the plug. Then, connect the black LED wire on the taller side. smaller taller 5- Secure the back with 3x14mm screws.
